Place of Origin: | China |
---|---|
Brand Name: | KAD |
Certification: | CE |
Model Number: | CDD1530 |
Minimum Order Quantity: | 1unit |
Price: | $2000-$3000 /unit |
Packaging Details: | Iron pallet+plastic film |
Delivery Time: | 15 working days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 500units/month |
Color: | Red/Customized | Product Name: | Electric Forklift |
---|---|---|---|
Load Center: | 500mm | Load Capacity: | 1000-1500kg |
Load Height: | 3000mm | Feature: | High Efficiency |
Battery Cpacity: | 24V/210Ah | ||
Highlight: | 1500mm Full Electric Stacker,2000kg Full Electric Stacker,24V Full Electric Stacker |
2000kg 1500mm 24V/210Ah Full Electric Stacker with CE certificate for Cold storage and food industry use
A full electric stacker with a large battery offers significant advantages in material handling operations. The large battery provides extended runtime, allowing the equipment to operate for longer shifts without frequent recharging, which increases productivity. It also ensures consistent performance over extended periods, reducing the need for downtime. This type of stacker is environmentally friendly, producing zero emissions and operating with minimal noise, making it ideal for indoor use. With fewer moving parts, maintenance requirements are reduced, lowering operational costs.
1. Medium intensity material handling, stacking and loading/unloading.
2. Designed for narrow aisles .
3. Only suitable for single-sided pallet use.
4. High-strength vertical gearbox improves transmission efficiency, reduces transmission noise, and has a long working life.
5. Folding pedals provide a comfortable working environment for operation.
6. Large-capacity battery ensures long time use.
MODEL
|
|
|
CDD12 CDD16 CDD20
|
|
Features
|
Drive system
|
|
|
Battery
|
Driving mode
|
|
|
Standing
|
|
Load Capacity
|
Q
|
KG
|
1200/1600/2000
|
|
Load Center
|
C
|
MM
|
500
|
|
Weight
|
Weight(With battery)
|
|
KG
|
830/880/910/940/970
|
Wheels
|
Material
|
|
|
PU
|
Size
|
Lifting Height
|
H3
|
MM
|
1600/2000/2500/3000/3500/4000/5000
|
Lowest Mast
|
H1
|
MM
|
2080/1580/1830/2080/2330/1820/2020
|
|
Max.Height
when operating |
H4
|
MM
|
2080/2730/3230/3730/4230/4460/4960
|
|
Min.Height of Fork
|
H13
|
MM
|
≤90
|
|
Length
|
L1
|
MM
|
2130
|
|
Width
|
B1
|
MM
|
850
|
|
Fork Length
|
L
|
MM
|
1070
|
|
Wheelbase
|
Y
|
MM
|
1430
|
|
Fork Outside Width
|
B5
|
MM
|
550/680
|
|
Fork Inside Width
|
|
MM
|
225/355
|
|
Min.Turning Radius
|
WA
|
MM
|
1738/2099
|
|
Performance
|
Driving Speed
(Empty/Full Load) |
|
MM/S
|
6.5/5.0
|
Lifting Speed
(Empty/Full Load) |
|
MM/S
|
80/50
|
|
Descending Speed
(Empty/Full Load) |
|
MM/S
|
120
|
|
Max.Gradient
(Empty/Full Load) |
|
°
|
6
|
|
Brake
|
|
|
Electromagnetic brake
|
|
|
Driving Motor
|
|
KW
|
DC/0.75/1.2/1.5
|
Lifting Motor
|
|
KW
|
DC/2
|
|
Battery
|
Capacity
|
|
V/Ah
|
24//210
|
Features of lightweight electric pallet stackers
The structure of electric pallet stacker is relatively simple and flexible in maneuvering. It is suitable for operation in narrow passages and limited space, and is an important vehicle equipment for warehouses, supermarkets, loading, unloading and stacking palletized goods.
1. energy efficient: the use of electric power drive, not only can improve work efficiency, but also can save energy.
2. Flexible: the equipment is compact and can move freely in a narrow space, and has good steering ability.
3. Simple operation: the control system is simple and easy to understand, the operator only needs to carry out simple instructions to realize the control of the equipment.
4. Safe and reliable: adopting hydraulic system, it can ensure the goods lifting and placing smoothly, and has the function of preventing accidents.
